Features:
Full Voltage Range;
Standby Energy Consumption: <0.48W (0.05A);
Intelligent temperature control, automatic regulation of fan speed according to the internal temperature of power supply, to effectively reduce noise;
Low ripple, low noise, high efficiency;
Overload protection, overvoltage protection, short circuit protection, overcurrent protection;
MTBF>=50,000 hours;
Meet the safety requirements of CCC, UL/CUL, CE, CB, TUV, NEMKO and BSMI.
Product Performance
| Type | LJ-TFX-280W | ||||
| Dimension | 175mm*70mm*85mm (W*H*L) | ||||
| Dimension of Fan | 80cm | ||||
| Efficiency | > 65% Full load | ||||
| AC Input Voltage | 90-264V, normal：100-240V | ||||
| DC Output | +3.3V | +5V | +12V | -12V | +5VSB |
| Max Current | 9A | 18A | 20.8A | 0.5A | 4A |
| Max Array Output | 100W | ||||
| 280W | |||||
| Output Wire Interface | 24-Pin Main*1 | 4-Pin CPU*1 | 15-Pin SATA*3 |
|
|
| 320mm | 610mm | 370mm+220mm+ 95mm |
|
|
|
LJ-SFX-300W-80PLUS Standard
LJ-SFX-400W-80PLUS Standard
LJ-SFX-350W-80PLUS Standard
LJ-TFX-280W
LJ-TFX-250W
