300W
Features:
Intelligent temperature control, automatic regulation of fan speed according to the internal temperature of power supply, to effectively reduce noise.;
Standby Energy Consumption: < 2W (0.18A);
Low ripple, low noise, high efficiency;
Overload protection, overvoltage protection and short circuit protection;
MTBF>=50,000 hours.
Product Performance
| Type | LJ-450BL-300W | |||||
| Dimension | 150mm*86mm*140mm (W*H*L) | |||||
| Dimension of Fan | 120cm | |||||
| Efficiency | > 68% Full load | |||||
| AC Input Voltage | 180-264V, normal：220V | |||||
| DC Output | +3.3V | +5V | +12V1 | +12V2 | -12V | +5VSB |
| Max Current | 20A | 20A | 8A | 14A | 0.3A | 2A |
| Max Array Output | 120W | |||||
| 290W | ||||||
| 300W | ||||||
| Output Wire Interface | 20-Pin Main*1 | 4-Pin CPU*1 | 15-Pin SATA*2 | 4-Pin IDE*2 | 4-Pin FDD*1 |
|
| 300mm | 400mm | 150mm+150mm | 400mm+200mm | 400mm |
|
|
